Material
Aluminum & Copper
Service Life
8 Years (Typical)
Closing Time
< 1 Second
| Parameter Specifications | |
|---|---|
| Applicable Gas | Petroleum liquefied gas with main components of propane/butane |
| Inlet Pressure | 0.03 ~ 1.56 MPa |
| Outlet Pressure | 2.80 kPa ± 0.50 kPa |
| Rated Flow Rate | 0.6 m³/h |
| Inlet Connection | M22×1.5 Right |
| Outlet Connection | G1/2 FPT |
| Service Life | 8 years (typical) |
| Material | Aluminum body + copper connector |
| Weight | 0.43 kg |
| Working Voltage | DC9V - 12V |
| Working Current | < 1.5A |
| Closing Time | < 1s |
| Working Environment | Temperature: (-20 ～ +45)°C, Humidity: 10%RH ～ 93%RH, Pressure: (86 ～ 106)kPa |
Q: What types of gas are compatible with this regulator?
The regulator is designed for petroleum liquefied gas (LNG/LPG systems) whose main components are propane and butane, making it suitable for household and small commercial usage.
Q: What are the inlet and outlet pressure limits?
It accommodates an inlet pressure range of 0.03 to 1.56 MPa, and accurately regulates the output to a stable 2.80kPa ± 0.50kPa for safe, consistent combustion.
Q: What materials are used in its construction and what is its lifespan?
It is constructed with a highly durable aluminum body and a corrosion-resistant copper connector. It has a typical design service life of 8 years, significantly reducing maintenance overhead.
Q: What electrical conditions are required for operation?
The regulator functions efficiently with a working voltage range of DC9V to 12V and a working current of less than 1.5A. It boasts an ultra-fast closing time of less than 1 second.
Q: Can this regulator be used in extreme weather conditions?
Yes, it operates reliably in ambient temperatures ranging from -20°C to +45°C, relative humidity levels from 10%RH to 93%RH, and atmospheric pressures between 86kPa and 106kPa.
