| Power Consumption | <1W |
| Communication Method | 4G |
| Display Method | Indicator Light |
| Power | DB9 interface power supply |
| Data Interface | Controller connection end: RS232A Host computer connection: R232B, RS485 |
| Communication Protocol | Controller: XGV2, XGV5 Host computer: XGV2, MODBUS |
| Cache Capacity | Input device: 256 points (detection channel) Output device: 64 points |
| Protection Grade | IP30 |
| Working Environment | Temperature: -10~+50℃ Humidity: 10~95%RH (non-condensing) |
description2
The device features ultra-low power consumption, requiring less than 1W (<1W) during operation.
It utilizes 4G communication. For protocols, the controller end supports XGV2 and XGV5, while the host computer connection supports XGV2 and MODBUS.
The device is powered via a DB9 interface connection, ensuring stable power delivery.
The controller connection side uses RS232A, and the host computer connection supports R232B and RS485 interfaces.
It operates reliably in temperatures ranging from -10 to +50℃, with a non-condensing relative humidity level between 10% and 95%RH.
The device is rated IP30, providing effective protection against solid foreign objects greater than 2.5mm.
