| Specification | BJX-24E | BJX-24E |
| Working Voltage | DC15V - DC32V | DC15V - DC32V |
| Sound Intensity | >75dB@1m | >80dB@1m |
| Body Material | Stainless steel 304 + PC | Aluminum alloy |
| Dimensions | ⌀43mm×70mm×81mm | L75mm×W48mm×H85.5mm |
| Installation Connection | G3/4" External Thread | M2.6 x 1.5 |
| Explosion-proof | Ex d IIC T6 Gb | Ex d IIC T6 Gb |
| Working Environment | Temperature: -10~+50℃, Humidity: 10~95%RH (non-condensing), Pressure: 86-106kPa | |
description2
The BJX-24E operates efficiently within a working voltage range of DC15V to DC32V.
Depending on the specific configuration, the body is constructed of either Stainless steel 304 + PC or Aluminum alloy.
The Stainless steel 304 + PC model provides a sound intensity of >75dB@1m, while the Aluminum alloy model offers >80dB@1m.
Yes, it features an explosion-proof certification rating of Ex d IIC T6 Gb, making it suitable for hazardous locations.
The installation connection options include G3/4" External Thread and M2.6 x 1.5, allowing for flexible mounting setups.
It operates reliably in temperatures ranging from -10 to +50℃, humidity levels of 10~95%RH (non-condensing), and air pressures of 86-106kPa.
